| Hardware Info |
| Processor |
Marvell 88MP1802 |
| Frequency |
LTE FDD : B1/ B3/ B7 (2100MHz/1800MHz/2600MHz) |
| LTE TDD : B38 / B39 / B40 / B41 (2570-2620/1880-1920/2300-2400/2555-2655MHz) |
| TD-SCDMA: B34 / B39 (2010-2025/1880-1920MHz) |
| UMTS : B1 / B2 / B5 /B8 (2100MHz/1900MHz/850MHz/900MHz) |
| GSM : B5 / B8 / B3 /B2 (850/900/1800/1900 MHz) |
| Peak rate |
LTE FDD : DL/UL 150 / 50 Mbps (Category 4) |
| LTE TDD : DL/UL 150 / 50Mbps (Category 4) |
TD-SCDMA: R5 1.28 TDD-HSDPA 2.8 Mbps DL
R7 1.28 TDD-HSUPA 2.2 Mbps UL
R8 1.28 TDD-HSPA+ 4.2 Mbps DL / 2.2 Mbps UL |
WCDMA : R99 384 kbps DL / UL
R5 HSDPA 7.2 Mbps DL
R6 HSUPA 5.76 Mbps UL
R7 HSPA+ 21 Mbps DL / 5.76 Mbps UL
R8 DC-HSPA+ 42 Mbps DL / 5.76 Mbps UL |
| GSM : DL/UL 384 / 384Kbps |
| Button |
1 WPS ON/OFF
1 Reset |
| T-Flash card |
Up to 32 GB |
| WIFI |
802.11 b/g/n |
| Port |
1 * USB2.0
1 * Standard USIM
1 * MicroSD |
| Antenna |
Internal |
| Working Temperature |
-10°C to 55°C |
| Working Humidity |
5% - 65% |
| Storage Temperature |
-20°C to 70°C |
| Storage Humidity |
5% to 95% |
| Software Info |
| OS |
WIN10,WIN8,Win7, Windows XP, Vista, Mac OS |
| Language |
Chinese&English |
| Sharing |
Up to 10 sharings |
| Settings |
Supported |
| SMS |
Supported |
| Contact Book |
Supported |
| APN Setting |
Supported |
| WIFI Settings |
Supported |
| Device Settings |
Supported |
| Routing Settings |
Supported |
| Firewall Settings |
Supported |
