Feature
|
Description
|
|
|
Form Factor
|
LTE Router
|
|
Interface
|
Network
|
4*lan 1*wan
|
|
SIM
|
2FF mini sim
|
|
USB
|
USB 2.0
|
|
Button
|
reset
|
|
DC adapter
|
Input voltage:
12V-1A
|
|
Solution
|
Routing and WiFi chipset supplier
|
MTK
|
|
BASE
|
Routing and WiFi chipset model
|
MT7620N
|
|
Routing and WiFi processor info
|
IEEE 80 2.11 /b/g/n
|
|
DDR/SPI
|
64MBytes/8MBytes
|
|
RF
|
Main antenna
|
Internal antenna
|
|
Receive diversity antenna
|
Internal antenna
|
|
WiFi band
|
2400MHz-2483.5MHz
|
|
MIMO for WiFi
|
2dbi X 2
|
|
Max. transmitter power for WiFi
|
802.11b 18dBm±2dBm;
802.11g 16dBm±2dBm;
802.11n 15dBm±2dBm;
|
|
Software
|
Language
|
Chinese&English
|
|
APN Setting
|
Supported
|
|
Device Settings
|
Supported
|
|
WIFI Settings
|
Supported
|
|
Routing Settings
|
Supported
|
|
Firewall Settings
|
Supported
|
|
LED
|
Supported
|
|
Technical standard
|
WiFi standard
|
802.11b/g/n(2*2 11n features)
|
|
WiFi security
|
WPA/WPA2
|
|
OS
|
Windows XP
|
|
Windows Vista
|
|
Windows 7
|
|
MAC
|
|
Linux
|
|
Browser
|
IE (7.0 and later)
|
|
Firefox (3.0 and later)
|
|
Safari (4.0 and later)
|
|
Opera (10.0 and later)
|
|
Chrome (10.0 and later)
|
|
Envionment
|
Operating temperature
|
-10 to 60° C
|
|
Storage temperature
|
-20 to 70° C
|
|
Humidity
|
5% to 95%
|
|
|
|
|
|
|
Feature
|
Description
|
|
|
Form Factor
|
Module
|
|
ID
|
Interface
|
Compliant with PCI Express Mini Card
|
|
SIZE
|
51*30*5mm
|
|
Solution
|
Wireless chipset supplier
|
Marvell
|
|
Base
|
Wireless chipset model
|
88MP1802
|
|
Wireless processor info
|
CAT4
|
|
USIM/SIM slot
|
Standard 6 PIN SIM card interface
3V SIM card and 1.8V SIM card
|
|
RF
|
Main antenna
|
Internal antenna
|
|
Receive diversity antenna
|
Internal antenna
|
|
GSM band
|
Band 3/8
|
|
UMTS band
|
Band 1
|
|
LTE FDD band
|
Band 3/8
|
|
MIMO for wireless
|
2 × 2 DL SU-MIMO for LTE and HSPA
|
|
Max. transmitter power for wireless
|
LTE: +23dBm
WCDMA: +24dBm (Power Class 3)
|
|
Technical standard
|
UMTS/LTE
|
WCDMA: HSDP DL 7.2Mbps
FDD LTE ：UL 50Mbps；DL150Mbps
|
|
3GPP release
|
FDD-LTE 3GPP Release 9
WCDMA Rel 4
|
|
Envionment
|
Operating temperature
|
-10°C to 55°C
|
|
Storage temperature
|
-20°C to 70°C
|
|
Humidity
|
5% to 95%
|
