Chipset： |
Ralink RT5372 |
| |
Interface Standard： |
USB2.0/1.1,type A
IEEE 802.11b/g/n |
| |
Antenna: |
1.5dbi antenna |
| |
Working Channel: |
1-13 |
| |
Transmission Rate: |
11n:Max 300Mbps
11g:6/9/12/18/24/36/48/54Mbps
11b:1/2/5.5/11Mbps |
| |
Frequency: |
2412GHZ～2483.5MHZ,ISM band |
| |
Modulation: |
BPSK,QPSK,CCK and OFDM(BPSK/QPSK/16-QAM) |
| |
Transmission power: |
802.11b:19+/-1.5dBm;
802.11g:14+/-1.5dBm;
802.11n:(HT20),14+/-1.5Bm,802.11n:(HT40),14+/-1.5Bm |
| |
Receiver sensitivity: |
802.11b:-84+/-1.5dBm@11Mbps;
802.11g:-69+/-1.5dBn@54Mbps;
802.11n:(HT20),-67@MCS7,1.5dBm,802.11n:(HT40),-63dBm@MCS7 |
| |
Application system: |
Windows CE/2000/XP/Vista/WIN8;Liux 2.6.X;Mac OS X |
| |
Security: |
WEP 64/128bit,WPA,WPA2,TKIP,AES |
| |
Temperature: |
Working:0℃～40℃ Celsius
Stock:-20℃～70℃ Celsius |
| |
Humidity： |
Working:10～95%(non-condensing)
Stock:5～95%(non-condensing) |
| |
SIZE: |
65*20.36*8.8mm |
