* Compatible with 802.11b/g/n wireless standards
* 2.4GHz frequency band
* Complies with Universal Serial Bus Rev. 2.0 specifications
* High speed transfer TX data rate up to 150 Mbps
* Supports wireless data encryption with 64/128-bit WEP, WPA, WPA2, TKIP, AES
* Wide range coverage,oursite used,waterproof antenna
* Support software AP
* Compliant with FCC Part 15.247 for US, ETS 300 328 for Europe
* Supports driver for Windows 2000, XP 32/64, Vista 32/64, Windows 7,win8, Mac ,linux
|
Hardware |
|
| |
Chipset： |
Ralink RT3070 |
| |
Interface： |
USB2.0/1.1, type A |
| |
Specification |
|
| |
Wireless Signal
Rates With
Automatic Fallback： |
IEEE 802.11n；IEEE 802.11g ；IEEE 802.11b |
| |
Frequency Range： |
2.4-2.4835GHz |
| |
Wireless Transmit Power： |
21dBm(EIRP) |
| |
Modulation Type： |
DBPSK, DQPSK, CCK, OFDM. |
| |
Receiver Sensitivity： |
150M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER. |
| |
Work Mode： |
Ad-Hoc Infrastructure, soft AP mode. |
| |
Wireless Security： |
WEP 64/128bit,WPA,WPA2,TKIP,AES |
| |
Software |
|
| |
Support Operating System： |
Windows2000/XP/Vista/Win7/Win8,Mac,Linux |
| |
Interface： |
USB2.0 Hi-Speed connector |
| |
Antenna Type： |
12dBi directional antenna |
| |
Operating Temperature： |
-40℃-70℃ |
| |
Storage Temperature： |
-40℃-70℃ |
| |
Relative Humidity： |
10%--- 95% RH (Non-Condensing) |
| |
Storage Humidity： |
5%--- 95% RH (Non-Condensing) |
| |
USB Cable |
5m/10m |
| |
Size |
105*200*28(mm) |
